Fitting -03 45° Teflon 6045-03D

Fitting -03 45° Teflon 6045-03D - Image 2

Fitting -03 45° Teflon 6045-03D

6045-03D

Thread "T"

3/4-16 UNF
3/8-24 UNF
7/16-20 UNF
9/16-18 UNF
M 12x1,5
M 14x1,5
M 18x1,5

A max. [mm]

30
34
34.5
41
41.5

B max. [mm]

10.1
12
13.5
13.7
14
16
20.5
8.3

C max. [mm]

19.4
21.2
21.4
21.8
23.2
23.9
25
33

I max. [mm]

2.3
4.2
6.7
9.6

SW1 [mm]

13
14.3
15
17.4
19
22

SW2 [mm]

15
19
22
11
